Detailed Product Description
S100, S1A, S1B, S100G, S100S Turbo Repair Kit Turbocharger Rebuild Kit Turbocharger Service Kit for DEUTZ PERKINS Diesel Engine.
Specifications:
Description | OE Part Number | Qty / Set |
Thrust Bearing | 169947 | 1 |
Journal Bearing | 312758 | 2 |
Retaining ring, bearing | 312760 | 4 |
Piston Ring, T/End | 313783 | 1 |
Piston Ring, C/End | 311857 | 1 |
O ring, c/hsg | 312553 | 1 |
O ring, plate | 311861 | 1 |
Insert plate | 315910 | 1 |
Flinger | 315909 | 1 |
Thrust ring | 312761 | 1 |
Oil deflector | 316419 | 1 |
Locknut | 316605 | 1 |
Bolt, comp. | 312345 | 4 |
Bolt, turb. | 315599 | 3 |
Retaining ring, plate | 311860 | 1 |
This repair kit can be used for repairing below turbos:
| Model | Part No. | Application |
S100 | 1147-988-0004 | SAME |
S100 | 1147-988-0007 | K.H.DEUTZ |
S100 | 316579 | VALMET |
S100 | 316608 | VALMET |
S100 | 317125 | K.H.DEUTZ |
S100 | 317206 | K.H.DEUTZ |
S100 | 318167 | K.H.DEUTZ |
S100 | 318279 | K.H.DEUTZ |
S100 | 318281 | K.H.DEUTZ |
S100 | 319073 | K.H.DEUTZ |
S100 | 319083 | K.H.DEUTZ |
S100 | 319184 | VALMET |
S100 | 319246 | K.H.DEUTZ |
S100 | 319247 | K.H.DEUTZ |
S100 | 319261 | K.H.DEUTZ |
S100 | 319302 | GREAVES |
S100 | 319335 | GREAVES |
S100G | 170424 | PERKINS |
S100G | 316757 | SISU |
S100G | 316797 | SISU |
S100G | 316943 | K.H.DEUTZ |
S100G | 317086 | K.H.DEUTZ |
S100G | 317236 | VALMET |
S100G | 317254 | K.H.DEUTZ |
S100G | 317279 | K.H.DEUTZ |
S100G | 317317 | VALMET |
S100G | 317709 |
